ABB UR600IR UR600 IR Flame Detector
$312.00
$589.00
What our customer's think
Reviews
Description
Overview
The ABB UR600 IR is a self-checking flame detector designed for reliable detection of individual burner flames in industrial combustion systems. It is specifically suitable for atomized oil and pulverized coal fuels. The detector provides the Uvisor MFD control unit with a raw flame signal, representing both the amplitude and flicker frequency of infrared radiation detected in the primary combustion zone. The Uvisor MFD uses advanced algorithms to process this signal, ensuring precise flame detection and excellent discrimination against background and adjacent burner flames.
Technical Specifications
- Sensor: PbS (Lead Sulphide)
- Spectrum Sensitivity: 0.6 ÷ 3 µm (Detectable infrared light range)
- Power Consumption: 300 mW DC, powered by Uvisor series control units
-
Ambient Temperature Operating Range:
- Operating: -10°C to 80°C (14°F to 176°F)
- Storage: -40°C to 100°C (-40°F to 212°F)
- Enclosure Protection: IP66 (NEMA 4X) – Provides protection against dust and water ingress
-
Hazardous Area Classification:
- EEx-d IIC T6
- ATEX category G-D
- CE Type Examination Certificate: CESI 03 ATEX 151
- Dimensions: 94 x 94 x 172 mm
- Weight: 1 kg (2.2 lbs)
Lens Cleaning and Airflow
- Air for Lens Cleaning: Clean ambient air
-
Air Flow for Lens Cleaning:
- Direct view: 115 l/min (4 SCFM)
- Extended probe: 400 l/min (14 SCFM)
-
Minimum Cleaning Air Pressure:
- Direct view: 20 mm H2O (1" W.C.) above the max wind box pressure
- Extended probe: 300 mm H2O (12" W.C.) above the max wind box pressure
Mounting and Electrical Connections
- Mounting Connection: 1" NPT male thread
- Cable Entry: 1/2" NPT female thread
-
Electrical Connections: 4 x 0.55 sq.mm (20 AWG) shielded cable
- Recommended maximum cable length: 300 meters (1000 feet)
- Compatible Amplifier Unit: Uvisor series amplifier
