Bently Nevada 3300/53-03-02-00-60-05-00-00-00 High-Temperature Proximity Transducer System
$167.00
$399.00
What our customer's think
Reviews
Description
Overview
The Bently Nevada 3300/53-03-02-00-60-05-00-00-00 is a high-temperature proximity transducer system designed to monitor rotating machinery. It measures both static (position) and dynamic (vibration) values. This system is ideal for fluid-film bearing machines, Keyphasor reference, and speed measurements.
Technical Specifications
-
Model Number: 3300/53-03-02-00-60-05-00-00-00
-
Type: High-Temperature Proximity Transducer System
-
Operating Temperature: Rated for temperatures up to +350°C (662°F)
-
Measurement Range: Measures static (position) and dynamic (vibration)
-
Sensor Type: Eddy Current Proximity Transducer
-
Accuracy: Complies with API 670 Standard (4th Edition)
-
Mounting Options: Available in DIN-rail and panel mount configurations
System Specifications
-
Temperature Range: +18°C to +27°C (+64°F to +80°F)
-
Altitude: Maximum altitude of 2000 meters
-
Power Supply: -24 Vdc with 10 kΩ load
-
Target Material: AISI 4140 steel target
-
Probe Gap: 1.27 mm (50 mils)
Electrical Specifications
-
Proximitor Sensor Input: Accepts 3300-series 5 mm or 3300 XL 8 mm proximity probes and extension cables.
-
Power Requirements: Requires -17.5 Vdc to -26 Vdc, 12 mA maximum consumption.
-
Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
-
Output Resistance: 50 Ω.
Features
Minimum Order Quantity (MOQ)
We welcome bulk orders and have a minimum order quantity of just one unit.
Certificates and Documentation
Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.
Delivery Time
For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.
Payment Methods
We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.
Warranty
We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.
Refund and Return Policy
Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
