EMERSON KJ3206X1-BK1 S-Series DI 8-Channel 24 VDC Isolated Card

EMERSON KJ3206X1-BK1 S-Series DI 8-Channel 24 VDC Isolated Card

  • 1000 In stock
  • Manufacturer: Emerson

  • Product No.: KJ3206X1-BK1

  • Condition: In stock

  • Product Type: S-Series DI 8-Channel 24 VDC Isolated Card

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 310g

  • Shipping port: Xiamen

  • Warranty: 12 months

{"id":41873603428442,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"KJ3206X1-BK1","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"EMERSON KJ3206X1-BK1 S-Series DI 8-Channel 24 VDC Isolated Card","public_title":null,"options":["Default Title"],"price":20700,"weight":310,"compare_at_price":31500,"inventory_management":"shopify","barcode":"USA","requires_selling_plan":false,"selling_plan_allocations":[]}

Description

Overview

The Emerson KJ3223X1-BK1 is a 16-channel Analog Input Module built for the DeltaV™ S-Series DCS. It accepts 4-20 mA HART signals from field devices. This module enables precise analog data collection for process automation systems.

Technical Specifications

General Information

  • Product Type: Analog Input Module

  • Model Number: KJ3223X1-BK1

  • System Compatibility: DeltaV™ S-Series DCS

  • Signal Type: 4-20 mA with HART

Input Channels

  • Number of Channels: 16

  • Channel Type: Isolated, current input with HART support

Power Requirements

  • Local Bus Power: 12 VDC at 150 mA

  • Bussed Field Power: 24 VDC at 600 mA

  • Field Circuit Power: 24 VDC at 30 mA per channel

Environmental Ratings

  • Operating Temperature: -40°C to +70°C

  • Shock: 10g, half-sine wave for 11 ms

  • Vibration:

    • 1 mm peak-to-peak from 2–13.2 Hz

    • 0.7g from 13.2–150 Hz

  • Humidity: 5% to 95%, non-condensing

  • Airborne Contaminants: ISA-S71.04–1985, Class G3

  • Terminal Block Key Position: A2

Features

Minimum Order Quantity (MOQ)

We welcome bulk orders and have a minimum order quantity of just one unit.

Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.

For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.

We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.

Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
