Epro A6220 Shaft Eccentricity Vibration Monitor

Epro A6220 Shaft Eccentricity Vibration Monitor

  • 1000 In stock
  • Manufacturer: Emerson

  • Product No.: A6220

  • Condition: In stock

  • Product Type: Shaft Eccentricity Vibration Monitor

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 900g

  • Shipping port: Xiamen

  • Warranty: 12 months

{"id":41475602219098,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"A6220","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Epro A6220 Shaft Eccentricity Vibration Monitor","public_title":null,"options":["Default Title"],"price":17300,"weight":900,"compare_at_price":34400,"inventory_management":"shopify","barcode":"USA","requires_selling_plan":false,"selling_plan_allocations":[]}

Description

Overview

The Epro A6220 Shaft Eccentricity Vibration Monitor is a dual-channel monitor designed for continuous monitoring of shaft eccentricity and vibration in rotating machinery. It is part of the AMS 6500 Machinery Health Monitor system and is specifically designed for use with standard eddy current shaft displacement probes.

Technical Specifications

  • Manufacturer: Epro (Emerson)
  • Product No.: A6220
  • Product Type: Shaft Eccentricity Vibration Monitor
  • Transducer Inputs: Two independent inputs
  • Type of Inputs: Eddy current, differential
  • Emerson Sensor Inputs: Part numbers: 6422, 6423, 6424, 6425
  • Isolation: Galvanically separated from power supply
  • Input Resistance: >100 kΩ
  • Input Voltage Range: -1 to 23 VDC
  • Input Frequency Range: 0.017 - 70 Hz (102 - 4200 rpm)
  • Module Size: Two-channel, 3U size, 1-slot plug-in module
  • Advantages: Decreases cabinet space requirements by half compared to traditional four-channel 6U size cards
  • API Compliance: API 670 compliant, hot-swappable module
  • Outputs: Front and rear buffered and proportional outputs, 0/4-20 mA output, 0 - 10 V output
  • Self-checking Facilities: Includes monitoring hardware, power input, hardware temperature, sensor, and cable
  • Use with Displacement Sensor: 6422, 6423, 6424, and 6425, driver CON XXX, and key monitoring module

Features

We welcome bulk orders and have a minimum order quantity of just one unit.

Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.

For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.

We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.

Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
