GE Fanuc IC3600SHPC101C Printed Circuit Board
$226.00
$565.00
What our customer's think
Reviews
Description
Overview
The IC3600SHPC101C is a PCB used in GE Fanuc's Mark I and Mark II gas turbine control systems, handling key data processing and control tasks.
Technical Specifications
- Compatibility: Designed for GE Fanuc Mark I and Mark II gas turbine control systems.
- Material Composition: A mix of silver, brown, and black metals for structural integrity and functionality.
- Control Interface: Equipped with a large grey knob positioned centrally on the left-side metal plate.
- Integrated Circuits: Contains three black integrated circuits, each clearly marked with part numbers for easy identification.
-
Capacitors: Features a range of capacitors:
- Yellow capacitors in various sizes (large, medium, small).
- Blue, square-shaped capacitors for specific filtering functions.
- Transistors: Includes four circular silver transistors for reliable signal amplification.
- Potentiometers: Two potentiometers located at the top of the PCB, with one being larger than the other.
-
Connection Terminals:
- A row of 51 silver prongs labeled in white along the right side, ensuring clear identification for wiring.
- Dimensions: Standard form factor typical of GE Fanuc PCBs for easy integration within turbine control units.
- Durability: Built with robust components, capable of enduring industrial environments.
Features
Minimum Order Quantity (MOQ)
We welcome bulk orders and have a minimum order quantity of just one unit.
Certificates and Documentation
Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.
Delivery Time
For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.
Payment Methods
We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.
Warranty
We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.
Refund and Return Policy
Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
