GE Fanuc UR8BV Digital Output Module

Overview

The GE Fanuc UR8BV is a digital output module for the GE Multilin Universal Relay (UR) series. It provides reliable digital output capabilities, ensuring effective control of external devices in protection and automation systems. Industries and utilities widely use this module because of its robust performance and seamless integration.

Technical Specifications

Model Information

• Model Number: UR8BV

• Type: Digital Output Module

Output and Electrical Ratings

• Outputs: 32 points, divided into 2 isolated groups of 16 points each

• Voltage Range: 5 VDC or 10-60 VDC

• Current Rating: 0.5 A per point

• Logic Type: Negative logic

Applications

• Industrial Automation: Supports precise digital control in automated systems

• Power Generation: Ensures efficient operation in power plants

• Process Control: Maintains stable and accurate system performance

Environmental Specifications

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

• Storage Temperature: -20°C to 70°C (-4°F to 158°F)

• Humidity: 5% to 95% non-condensing

Physical Dimensions

• Dimensions: 130 x 100 x 75 mm

• Weight: 0.5 kg
