Honeywell 10206/2/1 Digital Output Module

Honeywell 10206/2/1 Digital Output Module

  • 1000 In stock
  • Manufacturer: HONEYWELL

  • Product No.: 10206/2/1

  • Condition: In stock

  • Product Type: Digital Output Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

{"id":41839301361754,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"10206\/2\/1","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Honeywell 10206\/2\/1 Digital Output Module","public_title":null,"options":["Default Title"],"price":17700,"weight":500,"compare_at_price":50000,"inventory_management":"shopify","barcode":"USA","requires_selling_plan":false,"selling_plan_allocations":[]}

Description

Overview

The Honeywell 10206/2/1 is a digital output module designed for industrial automation. It provides twelve 24V DC output channels, each capable of driving loads up to 13W. This module is suitable for both resistive (e.g., lamps) and inductive (e.g., solenoids) loads.

Technical Specifications

  • Model Number: Honeywell 10206/2/1

  • Product Type: Digital Output Module

  • Number of Output Channels: 12

  • Supply Voltage: 24V DC (with two independent external supplies)

  • Maximum Current per Channel: 550 mA

  • Load Capacity: Up to 13W per channel

  • Suppression Diodes: Included for inductive loads

  • Output Groups: Two groups of six outputs, powered independently

  • Off-State Current: < 0.1 mA

  • Watchdog Control: Outputs de-energize if the system shuts down

  • Fail-Safe Status: Not tested for fail-safe applications
